Specifications
| Total Optical Output | 37.000mW |
| Scanning Speed | Juno 5 - 35kpps max 60° |
| Red Laser Module | 7.200mW - 638nm |
| Green Laser Module | 14.000mW - 525nm |
| Blue Laser Module | 20.000mW - 455nm |
| Beam Diameter | 6.0x6.0mm |
| Divergence | ˂ 1.3mrad, full angle |
| Analog Modulation | 0-5V - 100kHz |
| Power Consumption | ˂ 1000VA |
| Operating Temperature | 10-40 °C |
| IP Rating | IP20 |
| Weight | 30kg |
| Dimensions (LxWxH) | 396x510x273mm |
